Complexes

Complexes are combinations of several fabrics with or without a cut mat fixed by a mesh system, preferably by a polyester thread. We offer customized solutions by individually combining different layers.
A

Coroplex®

A

Multiaxial fabrics

A

Complex

Coroplex®

Coroplex® is a sandwich construction in which one, two or more E or ECR glass reinforcement materials (e.g. chopped strand mat, roving fabric, multiaxial scrims, nonwoven) are mechanically bonded to a PP nonwoven or PP knitted fabric. An almost unlimited number of combinations are possible.

In addition, Coroplex® is particularly suitable for the pressing and injection process (RIM, RTM) due to its excellent resin absorption.

Properties

KN MAM: very drapable, good formability, good resin flow, cutting stability

KN MA1M: for flat components, very fast resin flow, cutting stability

R

Markets

Wind power

Automotive



Your contact request

13 + 11 =

By sending your message, you agree to the processing of your data in accordance with our privacy policy. You can revoke this consent at any time.

Complex type KN MAM-150-180-150 KN MAM-300/135/300 KN MAM-300/250/300

Multiaxial fabrics

Multiaxial scrims consist of differently oriented thread layers that are fixed by a mesh system. These can be combined with nonwovens, cut mats or other fabrics. An almost unlimited number of combinations of different individual layers are possible.

Properties

Layer construction:

Unidirectional in 0° or 90°

Bidirectional in 0° and 90°

Multiaxial in variable alignment of the individual layers at angles of preferably ±45° , 90°, 0°

in width up to 330 cm

R

Markets

Sewer renovation

Wind power

Sports and leisure

Automotive – Vehicle superstructures



Your contact request

5 + 7 =

By sending your message, you agree to the processing of your data in accordance with our privacy policy. You can revoke this consent at any time.

Multiaxial designationtypeTotal mass per unit area in g/m²
KN G 340M2 biaxial 340
KN G 590.1 bidirectional 590
KN G 1240 M3 triaxial 1240
KN G 2400 M4 qudraxial 2400
KN GCA 430M2/300/40 biaxial with continuous mat and polyester fleece 770
KN GM 440M2/150 biaxial with cutting mat 590
KN GM 810M3/200 triaxial with cutting mat 1020
KN MG 100/520.3 unidirectional with cutting mat 630
KN MG 300/850 bidirectional with cutting mat 1150
KN MGM 200/600M2/200 biaxial with cut mat on both sides 1000
KN SG 30/700 Laying 0/90° with glass fleece 730

Complex

Textile glass complex is a sandwich construction in which two or more fabrics (e.g. roving fabric, fleece) are combined with a cut mat. An almost unlimited number of combinations are possible.

Properties

Combination of roving fabric, mats and nonwovens

Widths from 20 to 330 cm



R

Markets

Sewer renovation

Wind power

Sports and leisure

Industrial applications



Your contact request

11 + 6 =

By sending your message, you agree to the processing of your data in accordance with our privacy policy. You can revoke this consent at any time.

Complete typeTotal mass 1st layer 2nd layer 3rd layer
g/m 2 g/m 2 g/m 2 g/m 2
KN MR-300/300L5 610 300 300
KN MR-300/580L5 890 300 580
KN MR-450/500L5 960 450 500
KN MR-600/500L5 1110 600 500
KN MR-450/820L5 1280 450 820
KN MRM-300/300L5/300 910 300 300 300
KN ARM-60/300L5/300 670 60 300 300
KN MAM-600/250/600 1460 600 250 600
M = cutting mat, R = roving fabric, A = polyester fleece
